FEATURES:
– High strength-to-weight ratio
– Lightweight and flexible to reduce the risk of injuries
– Low elongation
– Minimal recoil at break
– High tenacity polyester cover to reduce the ingress of grit
– High abrasion resistance
– Protected 250mm soft eye splice terminations
– Certified Tonnage rating
– Traceability I/D Tags
– Strops to 350 tons
– Marine grade Thimbles available on request



Diameter (mm)

Length (m)

Safe working load

(Safety Factor 4:1)

Min Break Load

18mm

5m, 10m, 20m

5200kg

21000kg

24mm

5m, 10m, 20m

8700kg

35000kg

38mm

10m, 20m, 30m

12500kg

50000kg

44mm

10m, 20m, 30m

17500kg

70000kg

48mm

10m, 20m, 30m

16500kg

100000kg

65mm

10, 20m, 30m

37500kg

150000kg

75mm

10m, 20m, 30m

50000kg

200000kg

78mm

10m, 20m, 30m

62500kg

250000kg

82mm

10m, 20m, 30m

75000kg

300000kg

86mm

10m, 20m, 30m

87500kg

350000kg
